Point of Load Products
VPT's non-isolated, synchronous, buck regulated converters step down the voltage at the point of end use. These Hi-Rel POL modules are ultra light weight, have a tiny footprint, and offer incredible high efficiency to provide designers with a smaller, more affordable point-of-of use power converter option.
20 Results
Product | Datasheet | Product Type | TID | SEE | Temp. Range | Vin | Output Power/Current | Output Voltage | # Of Outputs | Series Image |
|---|---|---|---|---|---|---|---|---|---|---|
| DVPL0520S | Datasheet | Point of Load DC-DC Converters | NA | NA | -55°C to +125°C | 5 V | 20 A | 0.8 V to 3.4 V | 1 |  |
| SVGA0515SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 15 A | 0.8 V to 3.4 V | 1 |  |
| SVGA0515S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 15 A | 0.8 V to 3.4 V | 1 |  |
| SVFA0515SG | Datasheet | Point of Load DC-DC Converters | 40 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 15 A | 0.8 V to 3.4 V | 1 |  |
| SVFA0515S | Datasheet | Point of Load DC-DC Converters | 40 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 15 A | 0.8 V to 3.4 V | 1 |  |
| SVPL3R312SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V or 5 V | 12 A | 0.8 V to 3.8 V | 1 |  |
| SVPL3R312S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V or 5 V | 12 A | 0.8 V to 3.8 V | 1 |  |
| SVGA0510SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 10 A | 0.8 V to 3.4 V | 1 |  |
| SVGA0510S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 10 A | 0.8 V to 3.4 V | 1 |  |
| SVFA0510SG | Datasheet | Point of Load DC-DC Converters | 40 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 10 A | 0.8 V to 3.4 V | 1 |  |
| SVFA0510S | Datasheet | Point of Load DC-DC Converters | 40 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 10 A | 0.8 V to 3.4 V | 1 |  |
| DVPL0510S | Datasheet | Point of Load DC-DC Converters | NA | NA | -55°C to +125°C | 5 V | 10 A | 0.8 V to 3.4 V | 1 |  |
| SVPL1209SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V, 5 V, or 12 V | 9 A | 0.8 V to 5.0 V | 1 |  |
| SVPL1209S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V, 5 V, or 12 V | 9 A | 0.8 V to 3.4 V | 1 |  |
| SVRGA0508S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 8 A | 0.8 V to 3.4 V | 1 |  |
| SVPL3R306SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V or 5 V | 6 A | 0.8 V to 3.8 V | 1 |  |
| SVRPL3R306SG | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 5 V | 6 A | 0.8 V to 3.8 V | 1 |  |
| SVPL3R306S | Datasheet | Point of Load DC-DC Converters | 100 krad(Si) | 85 MeV/mg/cm² | -55°C to +125°C | 3.3 V or 5 V | 6 A | 0.8 V to 3.8 V | 1 |  |
| DVPL0505S | Datasheet | Point of Load DC-DC Converters | NA | NA | -55°C to +125°C | 5 V | 5 A | 0.8 V to 3.4 V | 1 |  |
| DVPL0503S | Datasheet | Point of Load DC-DC Converters | NA | NA | -55°C to +125°C | 5 V | 3 A | 0.8 V to 3.4 V | 1 |  |
