DVHV2800 SF

DVHV2800S Series

DVHV2812S DC-DC Converter

The DVHV Series of high reliability DC-DC converters is operable over the full military (-55 °C to +125 °C) temperature range with no power derating. Unique to the DVHV Series are robust and effective input and output filters which provide dramatically reduced input and output noise performance when compared to other manufacturers competing devices.

View DatasheetRequest a QuoteContact Sales

Select Output Voltage

Output Power/Current15 W
Output Voltage12 V
Nominal Input Voltage28 V
Continuous Input Voltage Range15 V to 50 V
# of Outputs1
Temperature Range-55°C to +125°C
SMD#5962-11226
EMI FilterDVMA28
Thermal PadsTP-003
